Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Over voltage category3
Rated insulation voltage Ui440V
Rated voltage230V
Ambient temperature during operating-25 - 75°C
Frequency50 - 60Hz
Release characteristicB
Rated current32A
Number of protected poles1
Pollution degree3
Connectable conductor cross section multi-wired1 - 25mm²
Built-in depth44mm
Suitable for flush-mounted installationYes
Current limiting class3
Voltage typeAC
Connectable conductor cross section solid-core1 - 25mm²
Additional equipment possibleYes
Degree of protection (IP)IP20
Width in number of modular spacings1
Concurrently switching neutral conductorNo
Number of poles (total)1
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
