Main Product Image

2CKA006197A0057 | UD/S4.315.2.1

Code: 1866180

ManufacturerABB
Catalog number2CKA006197A0057
EAN code4011395251966

Details

  • Installation bus systems
  • Dimming actuator for bus system
  • 1 KOM
  • ABB

Technical specifications

Mounting methodDRA (DIN-rail adapter)
ModelDimming actuator
Frequency50 - 60Hz
Bus system PowernetNo
Max. control current-mA
Type of loadUniversal and LED Retrofit
With bus connectionYes
Voltage230 - 230V
Other bus systemsNone
Bus system radio frequentNo
Width in number of modular spacings8
Bus system KNX radioNo
Degree of protection (IP)IP20
Parallel-service possibleYes
Output power315 - 315W
With LED indicationYes
Power boost suitableNo
Local operation/hand operationYes
Radio frequent bidirectionalNo
Min. depth of built-in installation box64.5mm
Substation inputNo
Bus system LONNo
Bus module detachableNo
Number of outputs4
Bus system KNXYes
Max. switching power LED315W
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
