Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Width288mm
Number of analogue inputs2
Number of digital outputs1
Number of HW-interfaces RS-2320
Number of analogue outputs2
With control elementYes
Height888.5mm
Supporting protocol for LONNo
Number of digital inputs8
Depth340.7mm
Power consumption1594W
Number of HW-interfaces industrial Ethernet1
Supporting protocol for PROFIBUSYes
Number of HW-interfaces RS-4220
Supporting protocol for TCP/IPYes
Number of HW-interfaces parallel0
Supporting protocol for CANYes
Number of HW-interfaces RS-4851
Number of HW-interfaces other1
Supporting protocol for INTERBUSNo
Supporting protocol for KNXNo
Number of HW-interfaces serial TTY0
Number of HW-interfaces USB0
Supporting protocol for Data-HighwayNo
Supporting protocol for SUCONETNo
Supporting protocol for ModbusYes
Supporting protocol for DeviceNetYes
Supporting protocol for ASINo
With optical interfaceNo
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for other bus systemsYes
4-quadrant operation possibleYes
Mains voltage380 - 500V
With PC connectionYes
Degree of protection (IP)IP21
Mains frequency50/60 Hz
Number of phases input3
Application in domestic- and commercial area permittedYes
Relative symmetric net voltage tolerance10%
Application in industrial area permittedYes
Integrated breaking resistanceYes
Number of phases output3
Relative symmetric net frequency tolerance10%
Supporting protocol for AS-Interface Safety at WorkNo
Max. output at quadratic load at rated output voltage90kW
Max. output at linear load at rated output voltage75kW
Max. output frequency400Hz
Type of converterU converter
Number of interfaces PROFINET0
Supporting protocol for DeviceNet SafetyNo
Max. output voltage500V
Supporting protocol for Foundation FieldbusNo
Supporting protocol for SafetyBUS pNo
Degree of protection (NEMA)1
Supporting protocol for PROFINET IOYes
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetYes
Nominal output current I2N140A
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET CBANo
