Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height500mm
Width400mm
Depth225mm
Motor drive integratedNo
Number of switches1
InterlockableYes
Number of auxiliary contacts as change-over contact0
Version as emergency stop installationYes
Type of control elementLong turning handle
Rated operation power at AC-3, 400 V0kW
Degree of protection (IP), front sideIP65
Version as main switchYes
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-23, 400 V90kW
Version as safety switchYes
Rated permanent current Iu160A
Number of poles3
Suitable for floor mountingYes
Number of auxiliary contacts as normally open contact0
Colour control elementRed
Version as maintenance-/service switchYes
Number of auxiliary contacts as normally closed contact0
Rated short-time withstand current lcw0kA
Suitable for distribution board installationNo
Suitable for front mounting 4-holeNo
Conditioned rated short-circuit current Iq100kA
Suitable for front mounting centreNo
Rated operating voltage690 - 690V
Degree of protection (NEMA)12
Switching power at 400 V90kW
Device constructionComplete device in housing
Version as reversing switchNo
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Rated permanent current at AC-21, 400 V160A
Suitable for intermediate mountingNo
Voltage release optionalNo
Rated permanent current at AC-23, 400 V160A
With pre-assembled cablingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DMVS-160/3/SE5/P-R
