Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height114mm
Degree of protection (IP), front sideIP65
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq100kA
Rated operation power at AC-3, 400 V0kW
Number of poles3
Width90mm
Number of switches1
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Depth150mm
Rated permanent current Iu30A
Number of auxiliary contacts as normally closed contact0
InterlockableYes
Type of control elementDoor coupling rotary drive
Suitable for floor mountingNo
Version as reversing switchNo
Version as safety switchNo
Device constructionBuilt-in device fixed built-in technique
Version as emergency stop installationYes
Voltage release optionalNo
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V0kW
Suitable for front mounting centreNo
Rated short-time withstand current lcw0kA
Switching power at 400 V0kW
Suitable for intermediate mountingNo
Version as main switchYes
Motor drive integratedNo
Suitable for front mounting 4-holeYes
Type of electrical connection of main circuitScrew connection
Motor drive optionalNo
Max. rated operation voltage Ue AC480V
Suitable for distribution board installationNo
Rated permanent current at AC-21, 400 V0A
Rated permanent current at AC-23, 400 V-A
Degree of protection (NEMA)12
With pre-assembled cablingNo
Colour control elementRed
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
P3-30/EA/SVB-MCS
