Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •1 KOM
  • •EATON

Technical specifications

Number of analogue outputs1
Width237mm
Number of analogue inputs2
Supporting protocol for LONYes
Height630mm
With control elementYes
Number of HW-interfaces RS-2321
Depth189mm
Number of HW-interfaces industrial Ethernet0
Number of digital inputs6
Number of digital outputs1
Number of HW-interfaces RS-4220
With optical interfaceNo
Number of HW-interfaces other0
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-4850
Supporting protocol for ASINo
Number of HW-interfaces parallel0
Supporting protocol for PROFIBUSYes
Supporting protocol for TCP/IPYes
Number of HW-interfaces USB0
With PC connectionYes
Supporting protocol for CANYes
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUSNo
Number of interfaces PROFINET0
Supporting protocol for other bus systemsYes
4-quadrant operation possibleYes
Supporting protocol for DeviceNetYes
Mains frequency50/60 Hz
Supporting protocol for ModbusYes
Supporting protocol for SUCONETNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for KNXNo
Supporting protocol for Data-HighwayYes
Supporting protocol for PROFINET CBANo
Relative symmetric net voltage tolerance10%
Application in industrial area permittedYes
Application in domestic- and commercial area permittedYes
Integrated breaking resistanceYes
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for PROFINET IOYes
Supporting protocol for BACnetNo
Supporting protocol for SafetyBUS pNo
Max. output frequency320Hz
Max. output at quadratic load at rated output voltage55kW
Degree of protection (NEMA)1
Supporting protocol for Foundation FieldbusNo
Max. output voltage500V
Relative symmetric net frequency tolerance10%
Type of converterU converter
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFIsafeNo
Supporting protocol for EtherNet/IPYes
Degree of protection (IP)IP21
Mains voltage323 - 550V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage45kW
Nominal output current I2N105A
