Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Width237mm
Height257mm
With control elementNo
Number of digital inputs6
Number of HW-interfaces RS-4220
Number of analogue inputs2
Number of analogue outputs1
Supporting protocol for LONNo
Number of HW-interfaces RS-2321
Number of HW-interfaces industrial Ethernet0
Depth640mm
Number of digital outputs1
Supporting protocol for ASINo
Supporting protocol for TCP/IPNo
Number of HW-interfaces RS-4850
With optical interfaceNo
Number of HW-interfaces serial TTY0
Number of HW-interfaces other0
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Supporting protocol for DeviceNetNo
Supporting protocol for CANNo
Supporting protocol for PROFIBUSNo
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusNo
4-quadrant operation possibleNo
Supporting protocol for Data-HighwayNo
Supporting protocol for SERCOSNo
Mains voltage380 - 500V
Supporting protocol for SUCONETNo
Degree of protection (IP)IP21
Supporting protocol for other bus systemsNo
Mains frequency50/60 Hz
Supporting protocol for KNXNo
Integrated breaking resistanceNo
Number of phases input3
Application in domestic- and commercial area permittedNo
Max. output at linear load at rated output voltage45kW
Max. output frequency320Hz
With PC connectionNo
Type of converterOther
Application in industrial area permittedNo
Supporting protocol for INTERBUS-SafetyNo
Number of interfaces PROFINET0
Number of phases output3
Max. output at quadratic load at rated output voltage55kW
Supporting protocol for PROFINET IONo
Supporting protocol for EtherNet/IPNo
Relative symmetric net frequency tolerance10%
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Max. output voltage500V
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for PROFINET CBANo
Relative symmetric net voltage tolerance10%
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Nominal output current I2N105A
Degree of protection (NEMA)Other
Supporting protocol for BACnetNo
