Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Depth1150mm
Height362mm
With control elementNo
Width480mm
Number of analogue inputs2
Number of digital inputs6
Number of HW-interfaces parallel0
Number of digital outputs1
Number of HW-interfaces RS-4220
Supporting protocol for TCP/IPNo
Supporting protocol for KNXNo
Supporting protocol for CANNo
Supporting protocol for ASINo
Number of HW-interfaces RS-4850
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-2321
Number of HW-interfaces USB0
Supporting protocol for INTERBUSNo
Supporting protocol for PROFIBUSNo
With optical interfaceNo
Number of analogue outputs1
Supporting protocol for LONNo
Number of HW-interfaces other0
Supporting protocol for other bus systemsNo
Supporting protocol for Data-HighwayNo
Supporting protocol for SUCONETNo
Supporting protocol for DeviceNetNo
Supporting protocol for ModbusNo
Number of HW-interfaces industrial Ethernet0
Mains frequency50/60 Hz
Max. output at quadratic load at rated output voltage132kW
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
4-quadrant operation possibleNo
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net voltage tolerance10%
Application in domestic- and commercial area permittedNo
Supporting protocol for DeviceNet SafetyNo
Application in industrial area permittedNo
Max. output frequency320Hz
Relative symmetric net frequency tolerance10%
Type of converterOther
With PC connectionNo
Integrated breaking resistanceNo
Supporting protocol for EtherNet/IPNo
Number of interfaces PROFINET0
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Max. output voltage690V
Degree of protection (NEMA)Other
Supporting protocol for BACnetNo
Degree of protection (IP)IP21
Mains voltage525 - 690V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage110kW
Nominal output current I2N144A
