Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Number of analogue inputs2
Number of HW-interfaces RS-4220
Number of digital inputs6
Height362mm
Number of HW-interfaces USB0
Number of HW-interfaces serial TTY0
Width480mm
Number of HW-interfaces industrial Ethernet0
Supporting protocol for LONNo
Number of analogue outputs1
Depth1150mm
Number of HW-interfaces RS-4850
Number of HW-interfaces RS-2321
Number of digital outputs1
With control elementNo
With optical interfaceNo
Supporting protocol for TCP/IPNo
Number of HW-interfaces other0
Supporting protocol for ASINo
Number of HW-interfaces parallel0
Supporting protocol for PROFIBUSNo
Supporting protocol for CANNo
Supporting protocol for ModbusNo
Supporting protocol for KNXNo
Supporting protocol for DeviceNetNo
Supporting protocol for INTERBUS-SafetyNo
Mains frequency50/60 Hz
Mains voltage525 - 690V
Supporting protocol for SERCOSNo
Degree of protection (IP)IP54
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
With PC connectionNo
Supporting protocol for INTERBUSNo
Supporting protocol for other bus systemsNo
4-quadrant operation possibleNo
Type of converterOther
Integrated breaking resistanceNo
Number of phases output3
Max. output at linear load at rated output voltage160kW
Number of phases input3
Max. output frequency320Hz
Application in domestic- and commercial area permittedNo
Application in industrial area permittedNo
Number of interfaces PROFINET0
Relative symmetric net frequency tolerance10%
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET IONo
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPNo
Max. output at quadratic load at rated output voltage200kW
Relative symmetric net voltage tolerance10%
Supporting protocol for PROFIsafeNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for BACnetNo
Max. output voltage690V
Degree of protection (NEMA)Other
Supporting protocol for SafetyBUS pNo
Nominal output current I2N208A
