Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Height362mm
Depth1150mm
Width480mm
With control elementNo
Number of digital inputs6
Number of analogue outputs1
Supporting protocol for LONNo
Number of HW-interfaces RS-4850
Number of analogue inputs2
Number of HW-interfaces RS-2321
Number of digital outputs1
Number of HW-interfaces RS-4220
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces serial TTY0
Number of HW-interfaces parallel0
Supporting protocol for TCP/IPNo
Supporting protocol for ASINo
Number of HW-interfaces USB0
With optical interfaceNo
Number of HW-interfaces other0
Supporting protocol for Data-HighwayNo
Supporting protocol for KNXNo
Supporting protocol for ModbusNo
Supporting protocol for INTERBUSNo
Supporting protocol for DeviceNetNo
Supporting protocol for PROFIBUSNo
Supporting protocol for CANNo
Supporting protocol for other bus systemsNo
Degree of protection (IP)IP21
With PC connectionNo
Supporting protocol for SERCOSNo
Supporting protocol for SUCONETNo
Supporting protocol for INTERBUS-SafetyNo
Mains voltage380 - 500V
4-quadrant operation possibleNo
Mains frequency50/60 Hz
Number of interfaces PROFINET0
Type of converterOther
Number of phases output3
Supporting protocol for AS-Interface Safety at WorkNo
Application in domestic- and commercial area permittedNo
Max. output frequency320Hz
Integrated breaking resistanceNo
Max. output at quadratic load at rated output voltage160kW
Application in industrial area permittedNo
Max. output at linear load at rated output voltage132kW
Relative symmetric net frequency tolerance10%
Number of phases input3
Relative symmetric net voltage tolerance10%
Supporting protocol for EtherNet/IPNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for SafetyBUS pNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFIsafeNo
Max. output voltage500V
Supporting protocol for DeviceNet SafetyNo
Nominal output current I2N300A
Degree of protection (NEMA)Other
Supporting protocol for BACnetNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPX200A1-4A1N1
