Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Number of digital inputs6
Width500mm
Depth1165mm
With control elementYes
Height506mm
Number of analogue inputs2
Number of digital outputs1
Number of HW-interfaces serial TTY0
Supporting protocol for LONYes
Number of analogue outputs1
Number of HW-interfaces RS-4851
Number of HW-interfaces RS-2320
Number of HW-interfaces RS-4220
Number of HW-interfaces industrial Ethernet0
Supporting protocol for PROFIBUSYes
With optical interfaceNo
Supporting protocol for INTERBUSNo
Number of HW-interfaces other1
Supporting protocol for TCP/IPYes
Supporting protocol for ASINo
Supporting protocol for CANYes
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Supporting protocol for Data-HighwayYes
Supporting protocol for other bus systemsYes
Mains voltage380 - 500V
Supporting protocol for KNXNo
With PC connectionYes
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for SUCONETNo
Supporting protocol for DeviceNetYes
Degree of protection (IP)IP00
Supporting protocol for ModbusNo
Supporting protocol for SERCOSNo
Number of phases output3
4-quadrant operation possibleYes
Mains frequency50/60 Hz
Number of interfaces PROFINET0
Type of converterU converter
Max. output frequency320Hz
Max. output at quadratic load at rated output voltage250kW
Number of phases input3
Relative symmetric net voltage tolerance10%
Integrated breaking resistanceNo
Application in industrial area permittedYes
Max. output at linear load at rated output voltage200kW
Application in domestic- and commercial area permittedYes
Nominal output current I2N460A
Supporting protocol for PROFINET CBANo
Relative symmetric net frequency tolerance10%
Max. output voltage500V
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for SafetyBUS pNo
Degree of protection (NEMA)Other
Supporting protocol for BACnetNo
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET IONo
Supporting protocol for AS-Interface Safety at WorkNo
