Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Number of HW-interfaces industrial Ethernet0
Depth468mm
Number of digital inputs6
Number of HW-interfaces RS-2321
With control elementYes
Supporting protocol for LONYes
Height1155mm
Number of analogue outputs1
With optical interfaceNo
Width709mm
Number of HW-interfaces RS-4220
Number of HW-interfaces other0
Number of HW-interfaces parallel0
Number of digital outputs1
Number of analogue inputs2
Number of HW-interfaces serial TTY0
Number of HW-interfaces USB0
Number of HW-interfaces RS-4850
Supporting protocol for SUCONETNo
Supporting protocol for CANYes
Supporting protocol for DeviceNetYes
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusYes
Supporting protocol for ASINo
Supporting protocol for other bus systemsYes
With PC connectionYes
Supporting protocol for KNXNo
Type of converterU converter
Number of interfaces PROFINET0
Mains frequency50/60 Hz
Supporting protocol for Data-HighwayYes
Supporting protocol for INTERBUS-SafetyNo
4-quadrant operation possibleYes
Supporting protocol for PROFIBUSYes
Supporting protocol for SERCOSNo
Supporting protocol for TCP/IPYes
Application in domestic- and commercial area permittedYes
Integrated breaking resistanceNo
Application in industrial area permittedYes
Relative symmetric net frequency tolerance10%
Relative symmetric net voltage tolerance10%
Supporting protocol for AS-Interface Safety at WorkNo
Max. output frequency320Hz
Max. output at quadratic load at rated output voltage450kW
Max. output voltage690V
Supporting protocol for BACnetNo
Supporting protocol for SafetyBUS pNo
Degree of protection (NEMA)1
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET IOYes
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for Foundation FieldbusNo
Degree of protection (IP)IP21
Mains voltage447 - 759V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage355kW
Nominal output current I2N460A
