Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
With control elementYes
Height1155mm
Number of digital inputs6
Width709mm
Depth468mm
Number of analogue outputs1
Supporting protocol for TCP/IPYes
Number of HW-interfaces USB0
Number of HW-interfaces RS-4850
Number of digital outputs1
Supporting protocol for INTERBUSNo
Supporting protocol for KNXNo
Number of HW-interfaces RS-4220
Supporting protocol for PROFIBUSYes
Supporting protocol for SUCONETNo
Supporting protocol for DeviceNetYes
Supporting protocol for ASINo
Number of HW-interfaces RS-2321
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces serial TTY0
Supporting protocol for CANYes
Number of HW-interfaces other0
Supporting protocol for ModbusYes
Supporting protocol for other bus systemsYes
With optical interfaceNo
Number of analogue inputs2
Number of HW-interfaces parallel0
Supporting protocol for LONYes
Degree of protection (IP)IP00
Supporting protocol for Data-HighwayYes
With PC connectionYes
Type of converterU converter
Number of interfaces PROFINET0
Mains voltage447 - 759V
Application in industrial area permittedYes
Integrated breaking resistanceNo
Supporting protocol for DeviceNet SafetyNo
Relative symmetric net frequency tolerance10%
Supporting protocol for INTERBUS-SafetyNo
Max. output frequency320Hz
Relative symmetric net voltage tolerance10%
Supporting protocol for Foundation FieldbusNo
Mains frequency50/60 Hz
Number of phases input3
4-quadrant operation possibleYes
Supporting protocol for PROFIsafeNo
Supporting protocol for AS-Interface Safety at WorkNo
Max. output at linear load at rated output voltage500kW
Number of phases output3
Supporting protocol for SERCOSNo
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET IOYes
Supporting protocol for PROFINET CBANo
Application in domestic- and commercial area permittedYes
Max. output at quadratic load at rated output voltage560kW
Supporting protocol for SafetyBUS pNo
Nominal output current I2N590A
Degree of protection (NEMA)Other
Max. output voltage690V
Supporting protocol for BACnetNo
