Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Number of HW-interfaces industrial Ethernet0
Supporting protocol for LONYes
Number of analogue inputs2
Height56.7mm
Width141.6mm
Number of digital outputs1
Number of analogue outputs1
Supporting protocol for ASINo
Number of HW-interfaces other1
Number of digital inputs6
Number of HW-interfaces RS-4220
Supporting protocol for TCP/IPYes
Depth105.6mm
Number of HW-interfaces RS-2320
With control elementYes
Number of HW-interfaces RS-4851
With optical interfaceNo
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Number of HW-interfaces serial TTY0
Supporting protocol for PROFIBUSYes
Supporting protocol for CANYes
Max. output frequency320Hz
4-quadrant operation possibleYes
Max. output at linear load at rated output voltage1100kW
Number of phases input3
With PC connectionYes
Application in industrial area permittedYes
Mains voltage380 - 500V
Supporting protocol for INTERBUSNo
Supporting protocol for DeviceNetYes
Supporting protocol for KNXNo
Type of converterU converter
Number of phases output3
Mains frequency50/60 Hz
Number of interfaces PROFINET0
Max. output at quadratic load at rated output voltage1200kW
Supporting protocol for SUCONETNo
Integrated breaking resistanceNo
Supporting protocol for other bus systemsYes
Application in domestic- and commercial area permittedYes
Supporting protocol for Data-HighwayYes
Degree of protection (IP)IP00
Supporting protocol for ModbusNo
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for EtherNet/IPNo
Relative symmetric net frequency tolerance10%
Relative symmetric net voltage tolerance10%
Max. output voltage500V
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET CBANo
Nominal output current I2N2150A
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetNo
Supporting protocol for PROFINET IONo
Degree of protection (NEMA)Other
