Details
- •Programmable logic controllers PLC
- •Fieldbus, decentr. periphery - analogue I/O module
- •1 KOM
- •EATON
Technical specifications
Number of HW-interfaces industrial Ethernet0
Number of analogue outputs8
Supporting protocol for LONNo
Depth104.2mm
Height16.8mm
Number of analogue inputs0
Width80.3mm
Power consumption1.4W
Suitable for safety functionsNo
Voltage type of supply voltageDC
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-2320
Number of HW-interfaces RS-4850
Supporting protocol for TCP/IPNo
Number of HW-interfaces parallel0
Supporting protocol for ASINo
Number of HW-interfaces other1
Supporting protocol for Data-HighwayNo
Input signal, configurableNo
Supporting protocol for other bus systemsYes
Number of HW-interfaces USB0
Number of HW-interfaces serial TTY0
Input, voltageNo
Supporting protocol for PROFIBUSNo
Supporting protocol for KNXNo
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusNo
Output, currentNo
Supporting protocol for CANNo
Supporting protocol for DeviceNetNo
Input, currentNo
Supporting protocol for SUCONETNo
Input, resistance thermometerNo
Input, resistorNo
Input, thermocoupleNo
Appendant operation agent (Ex ib)No
Type of electric connectionPlug-in connection
Rail mounting possibleYes
Explosion safety category for gasNone
Output signal configurableNo
Degree of protection (IP)IP20
Resolution of the analogue outputs12Bit
Appendant operation agent (Ex ia)No
Supporting protocol for SERCOSNo
System accessoryYes
Resolution of the analogue inputs0Bit
Output, voltageYes
Explosion safety category for dustNone
Front built-in possibleNo
IO link masterNo
Supporting protocol for AS-Interface Safety at WorkNo
Rack-assembly possibleNo
Supporting protocol for INTERBUS-SafetyNo
Radio standard BluetoothNo
Performance level according to EN ISO 13849-1None
Number of interfaces PROFINET0
Wall mounting/direct mountingNo
Radio standard Wi-Fi 802.11No
Number of HW-interfaces Wireless0
Fieldbus connection over separate bus coupler possibleYes
Supporting protocol for EtherNet/IPNo
Supporting protocol for DeviceNet SafetyNo
Supply voltage DC18 - 30V
Supporting protocol for PROFINET IONo
Analogue inputs configurableNo
Supply voltage AC 50 Hz0 - 0V
Supply voltage AC 60 Hz0 - 0V
Supporting protocol for PROFIsafeNo
Supporting protocol for SafetyBUS pNo
Certified for UL hazardous location group A (acetylene)No
Analogue outputs configurableYes
Certified for UL hazardous location class IIINo
Supporting protocol for Foundation FieldbusNo
Radio standard GSMNo
Certified for UL hazardous location division 1No
SIL according to IEC 61508None
Certified for UL hazardous location division 2No
Certified for UL hazardous location class INo
Certified for UL hazardous location class IINo
Degree of protection (NEMA)1
Supporting protocol for EtherCATNo
Certified for UL hazardous location group B (hydrogen)No
Supporting protocol for PROFINET CBANo
Radio standard UMTSNo
Radio standard GPRSNo
Certified for UL hazardous location group F (carbonaceous dusts)No
Certified for UL hazardous location group E (metal dusts)No
Certified for UL hazardous location group G (non-conductive dusts)No
Certified for UL hazardous location group D (propane)No
Certified for UL hazardous location group C (ethylene)No
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
XN-322-8AO-U2
