Details
- •Programmable logic controllers PLC
- •Graphic panel
- •1 KOM
- •EATON
Technical specifications
Power consumption5W
Number of HW-interfaces RS-2320
Screen diagonal3.5inch
Operating temperature0 - 50°C
Suitable for safety functionsNo
Built-in depth25mm
Number of HW-interfaces industrial Ethernet1
Voltage type of supply voltageDC
Supporting protocol for LONNo
Number of HW-interfaces RS-4220
Number of HW-interfaces parallel0
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-4850
Supporting protocol for ASINo
Supporting protocol for TCP/IPYes
Supporting protocol for PROFIBUSYes
Number of HW-interfaces USB1
Number of HW-interfaces other0
Supporting protocol for CANNo
Supporting protocol for DeviceNetNo
Supporting protocol for INTERBUSNo
Supporting protocol for Data-HighwayNo
Supporting protocol for ModbusYes
Supporting protocol for KNXNo
Supporting protocol for other bus systemsYes
Number of colours of the display32
Number of pixels, horizontal320
With colour displayNo
With alpha numeric keyboardYes
Supporting protocol for SUCONETNo
Number of pixels, vertical240
Useful project memory/user memory64000kByte
Number of function buttons, programmable0
With numeric keyboardYes
With message system (incl. buffer and confirmation)Yes
With recipesYes
Additional software components, loadableYes
With printer outputYes
Number of password levels200
With message indicationYes
Process value representation (output) possibleYes
Process default value (input) possibleYes
Number of online languages100
Degree of protection (IP), front sideIP65
Supporting protocol for AS-Interface Safety at WorkNo
Wall mounting/direct mountingNo
Supporting protocol for SERCOSNo
Number of HW-interfaces Wireless0
Rail mounting possibleNo
Supporting protocol for DeviceNet SafetyNo
Width of the front136mm
Supporting protocol for INTERBUS-SafetyNo
Height of the front100mm
Radio standard Wi-Fi 802.11No
Radio standard BluetoothNo
IO link masterNo
With SW interfacesYes
Number of interfaces PROFINET0
Supporting protocol for EtherNet/IPYes
Number of buttons with LED0
Supporting protocol for Foundation FieldbusNo
Type of displayTFT
Supporting protocol for PROFINET IONo
Supporting protocol for SafetyBUS pNo
Supply voltage AC 60 Hz0 - 0V
Radio standard GSMNo
Radio standard GPRSNo
Radio standard UMTSNo
Number of system buttons1
Supply voltage AC 50 Hz0 - 0V
Number of grey-scales/blue-scales of display32
Degree of protection (NEMA), front side4X
Touch technologyResistive touch
Supply voltage DC20.4 - 28.8V
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFIsafeNo
Certified for UL hazardous location division 1No
Certified for UL hazardous location class IIINo
Certified for UL hazardous location class INo
Certified for UL hazardous location group A (acetylene)No
Certified for UL hazardous location group B (hydrogen)No
Supporting protocol for EtherCATNo
Certified for UL hazardous location division 2No
Certified for UL hazardous location class IINo
Certified for UL hazardous location group C (ethylene)No
Certified for UL hazardous location group F (carbonaceous dusts)No
Certified for UL hazardous location group E (metal dusts)No
Certified for UL hazardous location group D (propane)No
Certified for UL hazardous location group G (non-conductive dusts)No
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
XV-102-A2-35MQR-10
