19002.2.M | 1P 20AX 1-way switch 2M Metal
Code: 1890744
Details
- •Domestic switching devices
- •Installation switch
- •1 KOM
- •VIMAR
Technical specifications
Wiring systemOff switch 1-pole
Method of operationRocker/button
Number of modules (module system)2
MaterialPlastic
Push button switchYes
Number of rockers1
With mounting plateNo
Halogen freeYes
Material qualityThermoplastic
Mounting methodFlush mounted (plaster)
Surface finishingMatt
Label space/information surfaceYes
Suitable for degree of protection (IP)IP40
Type of lightingLED exchangeable
RAL-number (similar)9007
Surface protectionLacquered
Assembly arrangementModular device for domestic switching devices
IlluminationOptional
ColourAluminium
Nominal voltage250V
Depth of device36.90mm
Built-in depth26.00mm
Rated current20.00A
Feedback-signal contactNo
Width of device44.80mm
Height of device49.00mm
Washing machine switchNo
Connection typeScrewed terminal
Type of fasteningEngage (snap)
Function lightingControl and orientation
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
