Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •HAGER
Technical specifications
Voltage typeAC
Current limiting class3
Rated current20A
Release characteristicC
Pollution degree2
Built-in depth70mm
Rated voltage230V
Frequency50 - 60Hz
Width in number of modular spacings2
Over voltage category3
Concurrently switching neutral conductorYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V-kA
Number of poles (total)2
Additional equipment possibleYes
Degree of protection (IP)IP20
Number of protected poles1
Suitable for flush-mounted installationYes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V-kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
