Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •HAGER
Technical specifications
Bus system KNXYes
Mounting methodFlush mounted (plaster)
Rated current0.85A
Output power200W
Rated operating voltage230 - 230V
Max. switching current1A
Bus system PowernetNo
With bus connectionYes
Max. number of switching contacts1
Bus system radio frequentNo
Width in number of modular spacings0
Max. switching power200W
Number of digital inputs2
Other bus systemsNone
Different phases connectableNo
Degree of protection (IP)IP20
Suitable for C-loadNo
Modular expandabilityNo
With LED indicationYes
Bus system LONNo
Radio frequent bidirectionalYes
Local operation/hand operationYes
Bus system KNX radioNo
Bus module detachableNo
Max. switching power LED50W
Min. depth of built-in installation box40mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
TRM690G
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Installation bus systems
- Switch actuator for bus system
- 1 KOM
- HAGER
DetailsTechnical specificationsRelated products
Technical specifications
Bus system KNX
Mounting method
Flush mounted (plaster)
Rated current
0.85A
Output power
200W
Rated operating voltage
230 .. 230V
Max. switching current
1A
Bus system Powernet
With bus connection
Max. number of switching contacts
1
Bus system radio frequent
Width in number of modular spacings
0
Max. switching power
200W
Number of digital inputs
2
Other bus systems
None
Different phases connectable
Degree of protection (IP)
IP20
Suitable for C-load
Modular expandability
With LED indication
Bus system LON
Radio frequent bidirectional
Local operation/hand operation
Bus system KNX radio
Bus module detachable
Max. switching power LED
50W
Min. depth of built-in installation box
40mm
