Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Number of digital outputs1
Number of analogue inputs3
Number of HW-interfaces RS-4220
Number of HW-interfaces serial TTY0
Supporting protocol for ASINo
Depth198.0mm
Number of digital inputs6
Number of analogue outputs1
With control elementYes
Number of HW-interfaces RS-2320
Supporting protocol for PROFIBUSYes
Number of HW-interfaces RS-4851
Number of HW-interfaces industrial Ethernet0
Supporting protocol for LONNo
Supporting protocol for TCP/IPYes
Number of HW-interfaces USB0
Width180.0mm
Number of HW-interfaces other1
Number of HW-interfaces parallel0
Supporting protocol for CANYes
Height330.0mm
With optical interfaceNo
Supporting protocol for INTERBUSNo
4-quadrant operation possibleYes
Mains frequency50/60 Hz
Supporting protocol for INTERBUS-SafetyNo
Degree of protection (IP)IP20
Application in domestic- and commercial area permittedNo
Supporting protocol for other bus systemsYes
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Max. output at linear load at rated output voltage15kW
Mains voltage380 - 500V
Integrated breaking resistanceYes
Relative symmetric net voltage tolerance10%
Number of phases output3
Max. output at quadratic load at rated output voltage15kW
With PC connectionYes
Supporting protocol for ModbusYes
Supporting protocol for SERCOSNo
Supporting protocol for KNXNo
Supporting protocol for DeviceNetYes
Application in industrial area permittedYes
Number of interfaces PROFINET0
Max. output frequency599Hz
Type of converterU converter
Number of phases input3
Relative symmetric net frequency tolerance5%
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for EtherNet/IPYes
Supporting protocol for Foundation FieldbusNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET IOYes
Supporting protocol for PROFIsafeNo
Max. output voltage550V
Degree of protection (NEMA)1
Supporting protocol for PROFINET CBANo
Nominal output current I2N66A
Supporting protocol for BACnetNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
ATV320D15N4C | ATV320 Compact 15KW - 3PH - 380/500V
