Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Number of digital outputs1
With control elementYes
Depth178mm
Width150mm
Number of HW-interfaces RS-2320
Height232mm
Number of analogue outputs1
Supporting protocol for LONNo
Number of HW-interfaces RS-4220
Number of HW-interfaces industrial Ethernet0
Number of digital inputs6
Supporting protocol for ASINo
Number of HW-interfaces other1
Supporting protocol for TCP/IPYes
Number of HW-interfaces parallel0
Number of HW-interfaces serial TTY0
Number of HW-interfaces USB0
With optical interfaceNo
Number of analogue inputs3
Number of HW-interfaces RS-4851
Supporting protocol for INTERBUSNo
Supporting protocol for Data-HighwayNo
Supporting protocol for CANYes
Supporting protocol for ModbusYes
Supporting protocol for PROFIBUSYes
Supporting protocol for KNXNo
Supporting protocol for other bus systemsYes
Number of phases input3
Number of interfaces PROFINET0
Application in industrial area permittedYes
Max. output frequency599Hz
Supporting protocol for DeviceNetYes
Supporting protocol for SERCOSNo
Integrated breaking resistanceYes
Application in domestic- and commercial area permittedNo
Degree of protection (IP)IP20
Mains voltage200 - 240V
Supporting protocol for SUCONETNo
With PC connectionYes
Type of converterU converter
Supporting protocol for INTERBUS-SafetyNo
Mains frequency50/60 Hz
4-quadrant operation possibleYes
Number of phases output3
Max. output at linear load at rated output voltage5.5kW
Max. output at quadratic load at rated output voltage5.5kW
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net frequency tolerance5%
Relative symmetric net voltage tolerance10%
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET IOYes
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFIsafeNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for BACnetNo
Degree of protection (NEMA)1
Nominal output current I2N27.5A
Max. output voltage240V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
ATV320U55M3C | Frek.pr. 5.5KW 200V 3PH-ATV320 Kompakt
