Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Depth262mm
Width213mm
Number of analogue inputs3
With control elementNo
Number of digital outputs1
Number of digital inputs8
Height660mm
Supporting protocol for KNXNo
Number of HW-interfaces serial TTY0
Supporting protocol for TCP/IPYes
Number of HW-interfaces RS-4220
Supporting protocol for Data-HighwayNo
Number of HW-interfaces RS-4851
Number of HW-interfaces other1
Number of HW-interfaces industrial Ethernet2
Supporting protocol for LONNo
Number of HW-interfaces parallel0
Supporting protocol for ASINo
Supporting protocol for CANNo
Number of HW-interfaces USB0
Number of HW-interfaces RS-2320
Supporting protocol for INTERBUSNo
With optical interfaceNo
Supporting protocol for ModbusYes
Supporting protocol for PROFIBUSNo
Number of analogue outputs2
Supporting protocol for other bus systemsNo
Supporting protocol for SUCONETNo
Supporting protocol for DeviceNetNo
Supporting protocol for SERCOSNo
With PC connectionYes
Supporting protocol for INTERBUS-SafetyNo
Number of interfaces PROFINET0
Mains frequency50/60 Hz
4-quadrant operation possibleYes
Type of converterU converter
Max. output frequency500Hz
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net frequency tolerance5%
Supporting protocol for Foundation FieldbusNo
Application in industrial area permittedYes
Application in domestic- and commercial area permittedNo
Integrated breaking resistanceNo
Relative symmetric net voltage tolerance10%
Supporting protocol for EtherNet/IPYes
Max. output at quadratic load at rated output voltage37kW
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFIsafeNo
Max. output voltage480V
Supporting protocol for PROFINET IONo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET CBANo
Degree of protection (NEMA)1
Supporting protocol for BACnetNo
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage37kW
Nominal output current I2N66.2A
