Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •1 KOM
  • •SCHNEIDER

Technical specifications

Number of digital outputs2
Number of digital inputs5
With control elementNo
Number of analogue inputs2
Depth232.5mm
Width85mm
Height270mm
Number of HW-interfaces serial TTY0
Supporting protocol for LONNo
Number of HW-interfaces industrial Ethernet2
Number of HW-interfaces RS-2320
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-4851
Number of analogue outputs1
Supporting protocol for PROFIBUSNo
Supporting protocol for ASINo
Number of HW-interfaces USB0
Number of HW-interfaces other1
Supporting protocol for INTERBUS-SafetyNo
With optical interfaceNo
Number of interfaces PROFINET0
With PC connectionYes
Supporting protocol for CANNo
Supporting protocol for SERCOSNo
4-quadrant operation possibleYes
Number of HW-interfaces parallel0
Supporting protocol for ModbusYes
Supporting protocol for TCP/IPYes
Supporting protocol for INTERBUSNo
Supporting protocol for Data-HighwayNo
Supporting protocol for KNXNo
Supporting protocol for other bus systemsNo
Supporting protocol for DeviceNetNo
Type of converterU converter
Mains frequency50/60 Hz
Supporting protocol for SUCONETNo
Max. output at quadratic load at rated output voltage1.1kW
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for Foundation FieldbusNo
Relative symmetric net frequency tolerance5%
Supporting protocol for PROFIsafeNo
Application in industrial area permittedYes
Supporting protocol for DeviceNet SafetyNo
Max. output voltage480V
Integrated breaking resistanceNo
Supporting protocol for BACnetNo
Supporting protocol for PROFINET CBANo
Max. output frequency599Hz
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET IONo
Application in domestic- and commercial area permittedNo
Supporting protocol for SafetyBUS pNo
Relative symmetric net voltage tolerance10%
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage1.1kW
Nominal output current I2N2.6A
