Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Depth225.5mm
Number of HW-interfaces RS-4853
Number of HW-interfaces USB0
Number of HW-interfaces industrial Ethernet0
With control elementYes
Number of analogue inputs3
Width195mm
Supporting protocol for LONNo
Number of HW-interfaces RS-2320
Number of analogue outputs2
Number of digital inputs8
Number of HW-interfaces RS-4220
Number of HW-interfaces serial TTY0
Height480mm
Number of digital outputs1
With optical interfaceNo
Supporting protocol for Data-HighwayNo
Supporting protocol for PROFIBUSYes
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusNo
Number of interfaces PROFINET0
Supporting protocol for KNXNo
With PC connectionNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for CANYes
Supporting protocol for TCP/IPNo
Supporting protocol for ASINo
Supporting protocol for DeviceNetYes
Supporting protocol for SUCONETNo
Supporting protocol for other bus systemsYes
Number of HW-interfaces other0
Number of HW-interfaces parallel0
Supporting protocol for SERCOSNo
4-quadrant operation possibleYes
Mains frequency50/60 Hz
Type of converterU converter
Application in domestic- and commercial area permittedYes
Integrated breaking resistanceNo
Max. output frequency500Hz
Max. output at quadratic load at rated output voltage15kW
Supporting protocol for PROFIsafeNo
Supporting protocol for EtherNet/IPYes
Supporting protocol for BACnetNo
Application in industrial area permittedYes
Max. output voltage480V
Supporting protocol for PROFINET CBANo
Supporting protocol for Foundation FieldbusNo
Relative symmetric net voltage tolerance10%
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net frequency tolerance5%
Supporting protocol for PROFINET IOYes
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage15kW
Nominal output current I2N31.7A
