Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Height597mm
Width210mm
Number of analogue inputs3
With control elementYes
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces other0
Number of digital inputs8
Supporting protocol for TCP/IPNo
Supporting protocol for ASINo
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-4220
Number of HW-interfaces parallel0
Number of HW-interfaces RS-2320
Number of digital outputs1
Number of HW-interfaces USB0
Supporting protocol for LONNo
Depth262mm
Number of HW-interfaces RS-4853
With optical interfaceNo
Supporting protocol for KNXNo
Supporting protocol for ModbusNo
Supporting protocol for DeviceNetYes
Supporting protocol for Data-HighwayNo
Supporting protocol for PROFIBUSYes
Supporting protocol for INTERBUSNo
Number of analogue outputs2
Supporting protocol for CANYes
With PC connectionNo
Type of converterU converter
Number of phases input3
Mains voltage380 - 480V
Number of interfaces PROFINET0
Supporting protocol for other bus systemsYes
Supporting protocol for INTERBUS-SafetyNo
Integrated breaking resistanceNo
Degree of protection (IP)IP20
Max. output frequency500Hz
Mains frequency50/60 Hz
Supporting protocol for SUCONETNo
Application in domestic- and commercial area permittedYes
Max. output at linear load at rated output voltage45kW
Application in industrial area permittedYes
Number of phases output3
4-quadrant operation possibleYes
Supporting protocol for SERCOSNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for EtherNet/IPYes
Relative symmetric net frequency tolerance5%
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Max. output at quadratic load at rated output voltage45kW
Relative symmetric net voltage tolerance10%
Supporting protocol for PROFINET CBANo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetNo
Max. output voltage480V
Nominal output current I2N88A
Supporting protocol for PROFINET IOYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
ATV930D45N4Z | Frek. Pret. IP21 45KW 400v/480v bez dis
