Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Depth196mm
With control elementYes
Number of digital inputs8
Width130mm
Height285mm
Number of digital outputs1
With optical interfaceNo
Number of HW-interfaces parallel0
Supporting protocol for LONNo
Number of HW-interfaces serial TTY0
Number of HW-interfaces USB0
Supporting protocol for PROFIBUSYes
Supporting protocol for KNXNo
Supporting protocol for other bus systemsYes
Number of analogue outputs2
Number of HW-interfaces other0
Supporting protocol for ASINo
Number of HW-interfaces RS-4853
Supporting protocol for SUCONETNo
Number of HW-interfaces industrial Ethernet0
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusNo
Supporting protocol for CANYes
Supporting protocol for TCP/IPNo
Number of HW-interfaces RS-2320
Number of analogue inputs3
Supporting protocol for DeviceNetYes
Supporting protocol for Data-HighwayNo
Number of HW-interfaces RS-4220
With PC connectionNo
Supporting protocol for EtherNet/IPYes
Relative symmetric net voltage tolerance10%
Supporting protocol for INTERBUS-SafetyNo
Number of interfaces PROFINET0
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET CBANo
4-quadrant operation possibleYes
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net frequency tolerance5%
Max. output at quadratic load at rated output voltage3kW
Application in domestic- and commercial area permittedYes
Type of converterU converter
Mains frequency50/60 Hz
Max. output frequency500Hz
Supporting protocol for DeviceNet SafetyNo
Integrated breaking resistanceNo
Application in industrial area permittedYes
Supporting protocol for PROFINET IOYes
Supporting protocol for PROFIsafeNo
Supporting protocol for SERCOSNo
Max. output voltage480V
Supporting protocol for BACnetNo
Supporting protocol for SafetyBUS pNo
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage3kW
Nominal output current I2N7.2A
