Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Width155mm
Depth225mm
Number of HW-interfaces RS-4220
Number of HW-interfaces serial TTY0
Number of digital inputs8
Number of HW-interfaces RS-2320
Number of digital outputs1
Number of analogue inputs3
With control elementYes
Number of HW-interfaces industrial Ethernet0
Supporting protocol for LONNo
Number of HW-interfaces RS-4853
Number of analogue outputs2
Supporting protocol for PROFIBUSYes
Supporting protocol for TCP/IPNo
Supporting protocol for CANYes
Supporting protocol for ASINo
Number of HW-interfaces other0
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Supporting protocol for KNXNo
Supporting protocol for INTERBUSNo
With optical interfaceNo
Supporting protocol for ModbusNo
Height345mm
Supporting protocol for Data-HighwayNo
Supporting protocol for DeviceNetYes
Mains frequency50/60 Hz
Type of converterU converter
Number of interfaces PROFINET0
Supporting protocol for SERCOSNo
Supporting protocol for SUCONETNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for other bus systemsYes
4-quadrant operation possibleYes
Integrated breaking resistanceNo
Supporting protocol for AS-Interface Safety at WorkNo
Max. output frequency500Hz
Application in industrial area permittedYes
Application in domestic- and commercial area permittedYes
Relative symmetric net voltage tolerance10%
Max. output at quadratic load at rated output voltage7.5kW
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for EtherNet/IPYes
With PC connectionNo
Relative symmetric net frequency tolerance5%
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IOYes
Supporting protocol for BACnetNo
Supporting protocol for PROFIsafeNo
Max. output voltage480V
Supporting protocol for SafetyBUS pNo
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage7.5kW
Nominal output current I2N16.5A
