Details

  • •
  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Height145mm
Width72mm
Number of digital outputs2
Number of HW-interfaces industrial Ethernet0
Number of digital inputs6
Depth140mm
With control elementYes
Number of analogue outputs1
Number of HW-interfaces RS-4221
Number of HW-interfaces RS-2320
Supporting protocol for LONNo
Number of analogue inputs3
Number of HW-interfaces USB0
Number of HW-interfaces RS-4850
Number of HW-interfaces other0
Supporting protocol for ASINo
Supporting protocol for TCP/IPNo
With optical interfaceNo
Supporting protocol for INTERBUSNo
Number of HW-interfaces parallel0
Supporting protocol for PROFIBUSNo
Number of HW-interfaces serial TTY0
Supporting protocol for CANNo
Supporting protocol for DeviceNetNo
Supporting protocol for Data-HighwayNo
Supporting protocol for KNXNo
Supporting protocol for ModbusNo
Supporting protocol for other bus systemsYes
With PC connectionNo
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
4-quadrant operation possibleNo
Mains frequency50/60 Hz
Number of interfaces PROFINET0
Supporting protocol for SUCONETNo
Integrated breaking resistanceNo
Application in industrial area permittedYes
Type of converterOther
Application in domestic- and commercial area permittedYes
Max. output frequency200000Hz
Relative symmetric net frequency tolerance5%
Relative symmetric net voltage tolerance10%
Max. output at quadratic load at rated output voltage0.27kW
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET IONo
Supporting protocol for PROFINET CBANo
Supporting protocol for BACnetNo
Supporting protocol for PROFIsafeNo
Max. output voltage24V
Degree of protection (IP)IP20
Mains voltage100 - 240V
Number of phases output3
Number of phases input1
Max. output at linear load at rated output voltage0.27kW
Nominal output current I2N2.5A
