Details
- •Domestic switching devices
- •Socket outlet
- •1 KOM
- •HAGER
Technical specifications
ModelProtective contact (SCHUKO)
Nominal current16A
ColourWhite
Mounting methodSurface mounted (plaster)
Halogen freeYes
CoverComplete housing
Nominal voltage250V
Number of units3
With on/off switchNo
Eject-mechanismNo
Material qualityThermoplastic
Label space/information surfaceNo
Connection typePush-in clamp
With hinged lidYes
Surface protectionUntreated
LockableNo
Rotated central insertNo
Frequency50 - 60Hz
With enhanced contact protectionNo
Special power supplyNo special power supply
Insulated mountingYes
MaterialPlastic
For heavy conditions (according to VDE)No
RAL-number (similar)9010
Type of fasteningMounting with screw
Over voltage protectionNo
Rated fault current-mA
Fault current protectionNo
Impact strengthIK05
Depth of device65mm
Number of socket outlets switchable0
TransparentNo
Imprint/indicationWithout imprint
Height of device76mm
Suitable for degree of protection (IP)IP55
Width of device218mm
With miniature fuseNo
Phase pickupNone
With loop through functionNo
With function lightingNo
Surface finishingMatt
With orientation lightingNo
With built-in USB power supplyNo
Number of modules (module system)-
