Details
- •Domestic switching devices
- •Socket outlet
- •1 KOM
- •HAGER
Technical specifications
ModelProtective contact (SCHUKO)
Mounting methodSurface mounted (plaster)
Nominal voltage250V
ColourWhite
Nominal current16A
LockableNo
Halogen freeYes
With hinged lidYes
Number of units2
CoverComplete housing
Surface protectionUntreated
Connection typePush-in clamp
Frequency50 - 50Hz
With enhanced contact protectionNo
Eject-mechanismNo
With on/off switchNo
Label space/information surfaceYes
Over voltage protectionNo
MaterialPlastic
Rotated central insertNo
Impact strengthIK05
Material qualityThermoplastic
Rated fault current-mA
Surface finishingMatt
For heavy conditions (according to VDE)No
Special power supplyNo special power supply
With miniature fuseNo
TransparentNo
Type of fasteningMounting with screw
Phase pickupNone
Insulated mountingYes
Imprint/indicationWithout imprint
With loop through functionNo
Fault current protectionNo
RAL-number (similar)9010
Width of device147mm
Suitable for degree of protection (IP)IP55
Number of socket outlets switchable0
Depth of device65mm
With function lightingNo
Height of device76mm
Number of modules (module system)-
With built-in USB power supplyNo
With orientation lightingNo
