47843512
Code: 1946302
Details
- •Domestic switching devices
- •Socket outlet
- •1 KOM
- •HAGER
Technical specifications
ModelProtective contact (SCHUKO)
Halogen freeYes
Mounting methodSurface mounted (plaster)
Material qualityThermoplastic
Surface finishingMatt
MaterialPlastic
Surface protectionUntreated
ColourWhite
RAL-number (similar)9010
Type of fasteningMounting with screw
Impact strengthIK05
Suitable for degree of protection (IP)IP55
TransparentNo
Label space/information surfaceNo
With hinged lidYes
Connection typePush-in clamp
Number of modules (module system)-
Width of device147mm
Nominal voltage250V
Height of device76mm
Frequency50 - 60Hz
Number of units2
Depth of device65mm
Imprint/indicationWithout imprint
LockableNo
Insulated mountingYes
Rotated central insertNo
Over voltage protectionNo
With enhanced contact protectionNo
With function lightingNo
Eject-mechanismNo
Fault current protectionNo
With built-in USB power supplyNo
For heavy conditions (according to VDE)Yes
Rated fault current-mA
With on/off switchNo
Number of socket outlets switchable0
With loop through functionNo
With orientation lightingNo
Special power supplyNo special power supply
With miniature fuseNo
CoverComplete housing
Phase pickupNone
Nominal current16A
