Details
- Domestic switching devices
- Socket outlet
- 1 KOM
- HAGER
Technical specifications
Nominal current
16A
Nominal voltage
250V
Mounting method
Flush mounted (plaster)
Colour
Aluminium
Model
Earthing pin
Halogen free
Yes
Number of units
1
Lockable
No
With hinged lid
Yes
Connection type
Screwed terminal
Surface protection
Anodised
With signal lamp
No
Number of phases
1
With enhanced contact protection
Yes
Frequency
50 - 60Hz
With on/off switch
No
Number of ports USB-A
0
Label space/information surface
No
Eject-mechanism
No
Material quality
Aluminium
Rotated central insert
No
Over voltage protection
No
Fault current protection
No
Special power supply
No special power supply
Insulated mounting
Yes
Material
Metal
Rated fault current
-mA
Type of fastening
Mounting with claw and screw
Imprint/indication
Other
RAL-number (similar)
9006
Impact strength
IK07
Transparent
No
Surface finishing
Matt
With miniature fuse
No
With loop through function
No
Suitable for degree of protection (IP)
IP20
Width of device
71mm
Height of device
71mm
Depth of device
42mm
Number of socket outlets switchable
0
With function lighting
No
With orientation lighting
No
Number of modules (module system)
1
IFTTT support available
No
Number of active pins (round)
2
Number of active pins (flat)
0
Min. depth of built-in installation box
35mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Number of ports USB-C
0
Number of active contacts (square)
0
Protective contact
Round
Number of loop throughs
1
Anti-bacterial treatment
No
For heavy conditions (according to VDE)
No
