40071353262 | Wall mounting SET, recessed mounting for GuideLed 11812, 1-8h/D, CGLine+, 30M
Code: 1953657
ManufacturerEaton
Catalog number40071353262
TypeEmergency luminaire
CategoryEmergency luminaire
EAN code4012539344230
Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Protection classII
Number of poles6
Power supply systemPeripheral (individual battery)
Type of control gearLED operating device voltage-controlled
Lamp typeLED not exchangeable
Built-in width115mm
Voltage typeAC
Length295mm
Material housingPlastic
Lamp holderOther
Height/depth45mm
Width115mm
Material coverPlastic, opal
Built-in length295mm
Colour housingGrey
Conductor cross section2.5mm²
Suitable for labelling typeInsert sheet/plate
Number of lighting heads1
Connection typePlug-in connection
With light sourceNo
Luminaire with limited surface temperature, sign "D“No
Impact strengthIK03
Battery qualityLithium-ions
Nominal voltage220 - 240V
Monitoring equipmentSafety module for monitoring (central feeded system)
Recognition distance30m
With remote switch connectionYes
With pictogramNo
Rated life time L70/B50 at 25 °C50000h
Rated luminous flux according to IEC 62722-2-1115lm
Light distributorDiffuser lens/optic/panel
Power factor0.88
Rated ambient temperature according to IEC62722-2-10 - 30°C
Type of wiringSuitable for through wiring
Nominal operation time1 - 8h
Built-in height/depth2mm
Mounting methodSurface mounting/recessed mounting
Degree of protection (IP)IP20
Max. system power4.7W
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
40071353262 | Wall mounting SET, recessed mounting for GuideLed 11812, 1-8h/D, CGLine+, 30M
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Luminaires
- Emergency luminaire
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Protection class
II
Number of poles
6
Power supply system
Peripheral (individual battery)
Type of control gear
LED operating device voltage-controlled
Lamp type
LED not exchangeable
Built-in width
115mm
Voltage type
AC
Length
295mm
Material housing
Plastic
Lamp holder
Other
Height/depth
45mm
Width
115mm
Material cover
Plastic, opal
Built-in length
295mm
Colour housing
Grey
Conductor cross section
2.5mm²
Suitable for labelling type
Insert sheet/plate
Number of lighting heads
1
Connection type
Plug-in connection
With light source
Luminaire with limited surface temperature, sign "D“
Impact strength
IK03
Battery quality
Lithium-ions
Nominal voltage
220 .. 240V
Monitoring equipment
Safety module for monitoring (central feeded system)
Recognition distance
30m
With remote switch connection
With pictogram
Rated life time L70/B50 at 25 °C
50000h
Rated luminous flux according to IEC 62722-2-1
115lm
Light distributor
Diffuser lens/optic/panel
Power factor
0.88
Rated ambient temperature according to IEC62722-2-1
0 .. 30°C
Type of wiring
Suitable for through wiring
Nominal operation time
1 .. 8h
Built-in height/depth
2mm
Mounting method
Surface mounting/recessed mounting
Degree of protection (IP)
IP20
Max. system power
4.7W
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
