40071353264 | Ceiling mounting SET for GuideLed 10821, 1-8h/D, CGLine+, canopy, 20M
Code: 1953659
ManufacturerEaton
Catalog number40071353264
TypeEmergency luminaire
CategoryEmergency luminaire
EAN code4012539344254
Details
- •Luminaires
- •Emergency luminaire
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Protection classII
Conductor cross section2.5mm²
Lamp holderOther
Width80mm
Voltage typeAC
Colour housingGrey
Connection typePlug-in connection
Type of control gearLED operating device voltage-controlled
Power supply systemPeripheral (individual battery)
Suitable for labelling typeInsert sheet/plate
Material coverPlastic, opal
Height/depth33mm
Type of indicatorSingle/double-sided
With light sourceNo
With remote switch connectionYes
Light distributorDiffuser lens/optic/panel
Impact strengthIK03
Luminaire with limited surface temperature, sign "D“No
Rated ambient temperature according to IEC62722-2-10 - 30°C
Monitoring equipmentSafety module for monitoring (central feeded system)
Number of poles6
Rated luminous flux according to IEC 62722-2-1115lm
Recognition distance20m
Rated life time L70/B50 at 25 °C50000h
Type of wiringSuitable for through wiring
Material housingPlastic
Length227mm
With pictogramNo
Lamp typeLED not exchangeable
Nominal voltage220 - 240V
Number of lighting heads1
Nominal operation time1 - 8h
Battery qualityLithium-ions
Power factor0.89
Mounting methodCeiling surface mounting
Degree of protection (IP)IP40
Max. system power5.1W
