Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Protection classII
Mounting methodBuilt-in
Width100mm
Colour housingGrey
Conductor cross section2.5mm²
Type of control gearLED operating device current-controlled
Power supply systemPeripheral (individual battery)
Lamp holderOther
Number of poles6
Connection typePlug-in connection
Built-in width100mm
Voltage typeAC
Suitable for labelling typeOther
Length500mm
Number of lighting heads1
Battery qualityLithium-ions
Material housingPlastic
Nominal voltage220 - 240V
With light sourceYes
Height/depth100mm
Built-in length100mm
Material coverPlastic, opal
Degree of protection (IP)IP41
Impact strengthIK03
Lamp typeLED not exchangeable
With remote switch connectionYes
Monitoring equipmentSafety module for monitoring (central feeded system)
Luminaire with limited surface temperature, sign "D“No
Type of wiringSuitable for through wiring
Colour temperature6500 - 6500K
Built-in height/depth5mm
With pictogramNo
Rated life time L70/B50 at 25 °C50000h
Power factor0.91
Rated ambient temperature according to IEC62722-2-10 - 30°C
Light distributorFocal lens
Nominal operation time1 - 8h
Rated luminous flux according to IEC 62722-2-1115lm
Max. system power6.7W
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
40071353274
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Luminaires
- Emergency luminaire
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Protection class
II
Mounting method
Built-in
Width
100mm
Colour housing
Grey
Conductor cross section
2.5mm²
Type of control gear
LED operating device current-controlled
Power supply system
Peripheral (individual battery)
Lamp holder
Other
Number of poles
6
Connection type
Plug-in connection
Built-in width
100mm
Voltage type
AC
Suitable for labelling type
Other
Length
500mm
Number of lighting heads
1
Battery quality
Lithium-ions
Material housing
Plastic
Nominal voltage
220 .. 240V
With light source
Height/depth
100mm
Built-in length
100mm
Material cover
Plastic, opal
Degree of protection (IP)
IP41
Impact strength
IK03
Lamp type
LED not exchangeable
With remote switch connection
Monitoring equipment
Safety module for monitoring (central feeded system)
Luminaire with limited surface temperature, sign "D“
Type of wiring
Suitable for through wiring
Colour temperature
6500 .. 6500K
Built-in height/depth
5mm
With pictogram
Rated life time L70/B50 at 25 °C
50000h
Power factor
0.91
Rated ambient temperature according to IEC62722-2-1
0 .. 30°C
Light distributor
Focal lens
Nominal operation time
1 .. 8h
Rated luminous flux according to IEC 62722-2-1
115lm
Max. system power
6.7W
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
