Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Connection typePlug-in connection
Length80mm
Mounting methodBuilt-in
Type of control gearLED operating device current-controlled
Outer diameter80mm
Built-in diameter64mm
Power supply systemCentral (central battery)
Height/depth40mm
Number of poles3
Voltage typeDC
Protection classII
Colour housingWhite
Width80mm
Conductor cross section2.5mm²
Degree of protection (IP)IP41
Nominal voltage220 - 240V
Lamp typeLED not exchangeable
Impact strengthIK03
Material housingPlastic
With remote switch connectionYes
Colour temperature6500 - 6500K
Monitoring equipmentSafety module for monitoring (central feeded system)
With pictogramNo
With light sourceYes
Built-in height/depth42mm
Light distributorFocal lens
Type of wiringSuitable for through wiring
Rated luminous flux according to IEC 62722-2-1250lm
Rated ambient temperature according to IEC62722-2-1-20 - 40°C
Luminaire with limited surface temperature, sign "D“No
