Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Conductor cross section2.5mm²
Colour housingWhite
Mounting methodBuilt-in
Width80mm
Connection typePlug-in connection
Voltage typeDC
Outer diameter80mm
Protection classII
Type of control gearLED operating device current-controlled
Built-in diameter64mm
Power supply systemCentral (central battery)
Number of poles3
Height/depth40mm
Rated luminous flux according to IEC 62722-2-1250lm
Degree of protection (IP)IP41
With remote switch connectionYes
Impact strengthIK03
Monitoring equipmentSafety module for monitoring (central feeded system)
Colour temperature6500 - 6500K
Nominal voltage220 - 240V
With light sourceYes
Rated ambient temperature according to IEC62722-2-1-20 - 40°C
With pictogramNo
Lamp typeLED not exchangeable
Type of wiringSuitable for through wiring
Luminaire with limited surface temperature, sign "D“No
Length80mm
Material housingPlastic
Built-in height/depth42mm
Light distributorFocal lens
