Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Protection classI
Mounting methodCeiling surface mounting
Connection typePlug-in connection
Width125mm
Conductor cross section2.5mm²
Type of control gearLED operating device current-controlled
Material housingPlastic
Number of poles3
Voltage typeDC
Length125mm
Colour housingWhite
Height/depth30mm
Lamp typeLED not exchangeable
With light sourceYes
Degree of protection (IP)IP41
With pictogramNo
Power supply systemCentral (central battery)
Nominal voltage220 - 240V
Light distributorFocal lens
Luminaire with limited surface temperature, sign "D“No
Colour temperature6500 - 6500K
Impact strengthIK03
With remote switch connectionYes
Rated luminous flux according to IEC 62722-2-1250lm
Type of wiringSuitable for through wiring
Monitoring equipmentSafety module for monitoring (central feeded system)
Rated ambient temperature according to IEC62722-2-1-20 - 40°C
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
40071354482
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Luminaires
- Emergency luminaire
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Protection class
I
Mounting method
Ceiling surface mounting
Connection type
Plug-in connection
Width
125mm
Conductor cross section
2.5mm²
Type of control gear
LED operating device current-controlled
Material housing
Plastic
Number of poles
3
Voltage type
DC
Length
125mm
Colour housing
White
Height/depth
30mm
Lamp type
LED not exchangeable
With light source
Degree of protection (IP)
IP41
With pictogram
Power supply system
Central (central battery)
Nominal voltage
220 .. 240V
Light distributor
Focal lens
Luminaire with limited surface temperature, sign "D“
Colour temperature
6500 .. 6500K
Impact strength
IK03
With remote switch connection
Rated luminous flux according to IEC 62722-2-1
250lm
Type of wiring
Suitable for through wiring
Monitoring equipment
Safety module for monitoring (central feeded system)
Rated ambient temperature according to IEC62722-2-1
-20 .. 40°C
