Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Protection classI
Mounting methodWall surface mounted
Width184mm
Lamp holderNone
Connection typePlug-in connection
With light sourceYes
Power supply systemPeripheral (individual battery)
Voltage typeAC
Monitoring equipmentSafety module for monitoring (central feeded system)
Material coverPlastic, transparent
Rated luminous flux according to IEC 62722-2-1250lm
Colour temperature6500 - 6500K
Number of poles6
With remote switch connectionYes
Length303mm
Type of control gearLED operating device current-controlled
Impact strengthIK10
Battery qualityLithium-ions
Nominal voltage220 - 240V
Suitable for labelling typeOther
Max. system power7W
Number of lighting heads1
Degree of protection (IP)IP65
Conductor cross section2.5mm²
Colour housingGrey
Luminaire with limited surface temperature, sign "D“Yes
Lamp typeLED not exchangeable
Height/depth160mm
Material housingAluminium
With pictogramNo
Rated ambient temperature according to IEC62722-2-15 - 35°C
Nominal operation time1 - 8h
Light distributorFocal lens
Rated life time L70/B50 at 25 °C50000h
Power factor0.91
Type of wiringSuitable for through wiring
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
40071354874
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Luminaires
- Emergency luminaire
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Protection class
I
Mounting method
Wall surface mounted
Width
184mm
Lamp holder
None
Connection type
Plug-in connection
With light source
Power supply system
Peripheral (individual battery)
Voltage type
AC
Monitoring equipment
Safety module for monitoring (central feeded system)
Material cover
Plastic, transparent
Rated luminous flux according to IEC 62722-2-1
250lm
Colour temperature
6500 .. 6500K
Number of poles
6
With remote switch connection
Length
303mm
Type of control gear
LED operating device current-controlled
Impact strength
IK10
Battery quality
Lithium-ions
Nominal voltage
220 .. 240V
Suitable for labelling type
Other
Max. system power
7W
Number of lighting heads
1
Degree of protection (IP)
IP65
Conductor cross section
2.5mm²
Colour housing
Grey
Luminaire with limited surface temperature, sign "D“
Lamp type
LED not exchangeable
Height/depth
160mm
Material housing
Aluminium
With pictogram
Rated ambient temperature according to IEC62722-2-1
5 .. 35°C
Nominal operation time
1 .. 8h
Light distributor
Focal lens
Rated life time L70/B50 at 25 °C
50000h
Power factor
0.91
Type of wiring
Suitable for through wiring
