Details
- •Luminaires
- •Emergency luminaire
- •1 KOM
- •EATON
Technical specifications
Mounting methodWall surface mounted
Type of control gearLED operating device voltage-controlled
Conductor cross section2.5mm²
Colour housingGrey
Protection classI
Voltage typeDC
Power supply systemCentral (central battery)
Width184mm
Connection typeScrew connection
Impact strengthIK10
Height/depth160mm
Monitoring equipmentSafety module for monitoring (central feeded system)
Lamp typeLED not exchangeable
With remote switch connectionYes
Colour temperature6500 - 6500K
Material housingAluminium
Recognition distance24m
Type of wiringSuitable for through wiring
Rated luminous flux according to IEC 62722-2-1225lm
Material coverPlastic, transparent
Rated ambient temperature according to IEC62722-2-1-20 - 40°C
Luminaire with limited surface temperature, sign "D“Yes
With pictogramNo
Number of poles3
Nominal voltage220 - 240V
With light sourceYes
Degree of protection (IP)IP65
Light distributorFocal lens
Length303mm
