Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •EATON
Technical specifications
Rated current6A
Rated operating voltage230 - 230V
Output power1380W
Bus system KNXNo
Mounting methodFlush mounted (plaster)
Bus system PowernetNo
Bus system radio frequentYes
Max. number of switching contacts2
Modular expandabilityYes
Bus system KNX radioNo
Bus module detachableNo
Width in number of modular spacings3
Number of binary inputs0
Max. switching current10A
Radio frequent bidirectionalYes
Local operation/hand operationNo
Different phases connectableNo
Degree of protection (IP)IP20
With LED indicationYes
Max. switching power1380W
Other bus systemsOther
Bus system LONNo
Suitable for C-loadNo
Min. depth of built-in installation box18mm
With bus connectionYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
CPAD-00/216
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Installation bus systems
- Switch actuator for bus system
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Rated current
6A
Rated operating voltage
230 .. 230V
Output power
1380W
Bus system KNX
Mounting method
Flush mounted (plaster)
Bus system Powernet
Bus system radio frequent
Max. number of switching contacts
2
Modular expandability
Bus system KNX radio
Bus module detachable
Width in number of modular spacings
3
Number of binary inputs
0
Max. switching current
10A
Radio frequent bidirectional
Local operation/hand operation
Different phases connectable
Degree of protection (IP)
IP20
With LED indication
Max. switching power
1380W
Other bus systems
Other
Bus system LON
Suitable for C-load
Min. depth of built-in installation box
18mm
With bus connection
