Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •EATON
Technical specifications
Bus system KNXNo
Bus system PowernetNo
With bus connectionYes
Max. switching current16A
Max. switching power3680W
Output power3680W
Mounting methodFlush mounted (plaster)
Rated current16A
Rated operating voltage230 - 230V
Width in number of modular spacings3
Bus system radio frequentYes
Max. number of switching contacts1
Number of binary inputs1
Other bus systemsxComfort
Degree of protection (IP)IP20
Different phases connectableNo
Suitable for C-loadYes
Bus system LONNo
Local operation/hand operationYes
With LED indicationYes
Min. depth of built-in installation box18mm
Bus module detachableYes
Modular expandabilityNo
Bus system KNX radioNo
Radio frequent bidirectionalYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
CSAU-01/01-16IE
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Installation bus systems
- Switch actuator for bus system
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Bus system KNX
Bus system Powernet
With bus connection
Max. switching current
16A
Max. switching power
3680W
Output power
3680W
Mounting method
Flush mounted (plaster)
Rated current
16A
Rated operating voltage
230 .. 230V
Width in number of modular spacings
3
Bus system radio frequent
Max. number of switching contacts
1
Number of binary inputs
1
Other bus systems
xComfort
Degree of protection (IP)
IP20
Different phases connectable
Suitable for C-load
Bus system LON
Local operation/hand operation
With LED indication
Min. depth of built-in installation box
18mm
Bus module detachable
Modular expandability
Bus system KNX radio
Radio frequent bidirectional
