Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Height85mm
Width45mm
Depth115mm
Rated operation power at AC-3, 400 V5.5kW
Modular versionNo
Rated operation current Ie at AC-3, 400 V14A
Rated control supply voltage Us at DC0 - 0V
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Number of auxiliary contacts as normally closed contact1
Operating voltage at AC 60 Hz24 - 690V
Rated control supply voltage Us at AC 50HZ220 - 220V
Number of auxiliary contacts as normally open contact1
Rated operation current Ie at AC-4, 400 V7A
Rated operation power at AC-4, 400 V3kW
Rated operation current Ie at AC-1, 400 V45A
Rated operation power NEMA0kW
Voltage type for actuatingAC
Type of electrical connection of main circuitSpring clamp connection
Rated control supply voltage Us at AC 60HZ220 - 220V
Operating voltage at AC 50 Hz24 - 690V
