Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Built-in depth75.5mm
Voltage typeAC
Rated current40A
Leakage current typeA
Rated insulation voltage Ui500V
Surge current capacity3kA
Rated voltage240V
Rated fault current0.3A
Number of protected poles1
Concurrently switching neutral conductorYes
Width in number of modular spacings2
Frequency50 Hz
Degree of protection (IP)IP20
Current limiting class3
Connectable conductor cross section multi-wired1 - 25mm²
Over voltage category3
Rated short-circuit breaking capacity according to IEC 60947-210kA
Pollution degree2
Connectable conductor cross section solid-core1 - 25mm²
Release characteristicC
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Disconnection characteristicUndelayed
Flush-mounted installationNo
Anti-nuisance tripping versionYes
Ambient temperature during operating-25 - 40°C
Rated short-circuit breaking capacity according to EN 6100910kA
Rated impulse withstand voltage Uimp4kV
With interlocking deviceNo
Number of poles (total)2
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBmM-C40/1N/03-F
