MP2O3HCGL | Emergency luminaire Micropoint 2, 3H Mtd, Open-space, CGLine+
Code: 1957850
ManufacturerEaton
Catalog numberMP2O3HCGL
TypeEmergency luminaire
CategoryEmergency luminaire
EAN code5018987195980
Details
- •Luminaires
- •Emergency luminaire
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Width29mm
Voltage typeAC
Connection typeScrew connection
Colour housingWhite
Outer diameter90mm
Lamp holderNone
Conductor cross section2.5mm²
Protection classII
Power supply systemPeripheral (individual battery)
Number of poles4
Type of control gearLED operating device current-controlled
Length198mm
Suitable for labelling typeOther
Built-in diameter64mm
Height/depth3mm
Material housingPlastic
Material coverOther
Lamp typeLED not exchangeable
Number of lighting heads1
Impact strengthIK04
Nominal voltage220 - 240V
With light sourceYes
Suitable for number of lamps1
Luminaire with limited surface temperature, sign "D“Yes
With remote switch connectionYes
Battery qualityNiCd
Colour temperature6200 - 6200K
Monitoring equipmentSafety module for monitoring (central feeded system)
Type of wiringSuitable for through wiring
Luminous flux in standby mode153lm
Rated luminous flux according to IEC 62722-2-1153lm
Light distributorFocal lens
Built-in height/depth63mm
Power factor0.5
Nominal operation time3 - 3h
With pictogramNo
Rated ambient temperature according to IEC62722-2-15 - 35°C
Mounting methodBuilt-in
Degree of protection (IP)IP44
Max. system power2.5W
