NEXI100-3H-AT | Emergency luminaire NexiTech LED 100LM 3H Autotest
Code: 1957948
ManufacturerEaton
Catalog numberNEXI100-3H-AT
TypeEmergency luminaire
CategoryEmergency luminaire
EAN code3660191600174
Details
- •Luminaires
- •Emergency luminaire
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Width110mm
Protection classII
Type of control gearLED operating device current-controlled
Connection typePlug-in connection
Power supply systemPeripheral (individual battery)
Lamp holderNone
Voltage typeAC
Colour housingWhite
Conductor cross section2.5mm²
Built-in width95mm
Lamp typeLED not exchangeable
Built-in length272mm
Number of lighting heads16
Height/depth40mm
Material housingPlastic
Number of poles2
Length290mm
Material coverPlastic, transparent
Suitable for number of lamps1
Suitable for labelling typeInsert sheet/plate
Monitoring equipmentAutomatic self test
With light sourceYes
Impact strengthIK03
Luminaire with limited surface temperature, sign "D“No
Nominal voltage220 - 240V
Battery qualityNiCd
With remote switch connectionYes
With pictogramNo
Rated luminous flux according to IEC 62722-2-1100lm
Luminous flux in standby mode70lm
Colour temperature5053 - 5053K
Recognition distance20m
Rated ambient temperature according to IEC62722-2-15 - 30°C
Power factor0.55
Nominal operation time3 - 3h
Built-in height/depth96mm
Light distributorReflector
Mounting methodSurface mounting/recessed mounting
Degree of protection (IP)IP40
Max. system power1.3W
