NEXI3HIACGLIP | Emergency luminaire NexiTech LED with function IA 3H IP65 CGLine+
Code: 1957990
ManufacturerEaton
Catalog numberNEXI3HIACGLIP
TypeEmergency luminaire
CategoryEmergency luminaire
EAN code3660191609290
Details
- •Luminaires
- •Emergency luminaire
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Type of control gearLED operating device current-controlled
Power supply systemPeripheral (individual battery)
Width125mm
Lamp holderNone
Protection classII
Colour housingWhite
Conductor cross section2.5mm²
Connection typePlug-in connection
Voltage typeAC
Length308mm
Built-in width95mm
Suitable for labelling typeInsert sheet/plate
Material housingPlastic
Number of poles2
Height/depth53mm
Built-in length272mm
Nominal operation time3 - 3h
Battery qualityNiCd
Number of lighting heads48
Material coverPlastic, transparent
Impact strengthIK07
Luminous flux in standby mode80lm
Suitable for number of lamps1
With light sourceYes
Rated luminous flux according to IEC 62722-2-180lm
With remote switch connectionYes
Rated ambient temperature according to IEC62722-2-15 - 30°C
Monitoring equipmentSafety module for monitoring (central feeded system)
Nominal voltage220 - 240V
Lamp typeLED not exchangeable
Luminaire with limited surface temperature, sign "D“No
With pictogramYes
Colour temperature5053 - 5053K
Built-in height/depth96mm
Light distributorReflector
Power factor0.41
Recognition distance20m
Mounting methodSurface mounting/recessed mounting
Degree of protection (IP)IP65
Max. system power3.9W
