PV-DIS-06-125/2
Code: 1959357
Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Number of switches1
Rated permanent current Iu0A
Version as reversing switchNo
Version as safety switchNo
Rated operating voltage600 - 1000V
Version as maintenance-/service switchYes
Rated permanent current at AC-21, 400 V0A
Version as main switchNo
Rated short-time withstand current lcw1500kA
Rated operation power at AC-3, 400 V0kW
Switching power at 400 V0kW
Max. rated operation voltage Ue AC0V
Version as emergency stop installationNo
Number of auxiliary contacts as normally closed contact0
Rated permanent current at AC-23, 400 V0A
Number of poles2
Conditioned rated short-circuit current Iq0kA
Rated operation power at AC-23, 400 V0kW
Number of auxiliary contacts as normally open contact0
Suitable for front mounting 4-holeNo
Device constructionBuilt-in device fixed built-in technique
Voltage release optionalYes
Motor drive optionalNo
Suitable for floor mountingNo
Number of auxiliary contacts as change-over contact0
Motor drive integratedNo
With pre-assembled cablingNo
Suitable for intermediate mountingNo
Width54mm
Degree of protection (NEMA)Other
Type of control elementRocker lever
Suitable for front mounting centreNo
Colour control elementGrey
Suitable for distribution board installationYes
Degree of protection (IP), front sideIP20
Type of electrical connection of main circuitFrame clamp
InterlockableNo
Height77mm
Depth113mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
