Details
- •Luminaires
- •Luminaire for streets and places
- •1 KOM
- •GEWISS
Technical specifications
Voltage typeAC
Connection typeScrewed terminal
Mounting methodPost top
Colour housingGrey
Protection classII
Conductor cross section2.5mm²
Surface protectionPowder coating
Lamp holderNone
Width330mm
Type of control gearLED operating device current-controlled
Material coverGlass structured
Material housingAluminium
Impact strengthIK08
Suitable for number of lamps1
Length560mm
With connection cableNo
With light sensorNo
Colour rendering index CRI70-79
Number of poles2
Luminaire with limited surface temperature, sign "D“No
Height/depth215mm
With control gearYes
Nominal voltage220 - 240V
Rated luminous flux according to IEC 62722-2-15000lm
Colour temperature4000 - 4000K
Suitable for spigot size42 - 76mm
With light sourceYes
Degree of protection (IP)IP66
Colour of lightWhite
Nominal current1000 - 1000mA
Lamp typeLED not exchangeable
Max. system power37W
Adjustable opticsNo
With radio controlNo
Remote controlNone
With light regulation program controlNo
Dimming phase cut-onNo
Colour consistency (McAdam ellipse)SDCM5
IFTTT support availableNo
Dimming phase cut-offNo
Rated ambient temperature according to IEC62722-2-1-25 - 40°C
Dimming programmableNo
Dimming 1-10 VYes
Dimming potentiometer (integrated)No
Dimming Sine Wave ReductionNo
Dimming mains voltage modulationNo
Dimming RFNo
Dimming DMXNo
Dimming DALINo
Constant light output (CLO)No
Dimming 0-10 VNo
Dimming Touch and DimNo
Type of wiringEnding
Dimming manufacturer's proprietary systemNo
Dimming LineSwitchNo
No dim functionNo
Dimming with push-buttonNo
Light distributorReflector
Dimming ZigbeeNo
Luminaire efficacy135lm/W
Operation by BluetoothNo
Type of connection for sensor/communication moduleOther
Compatible with Amazon AlexaNo
Compatible with Apple HomeKitNo
Compatible with Google AssistantNo
Dimming DSINo
Exchangeable control gearYes
Power factor0.9
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
MVN1210EF
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Luminaires
- Luminaire for streets and places
- 1 KOM
- GEWISS
DetailsTechnical specifications
Technical specifications
Voltage type
AC
Connection type
Screwed terminal
Mounting method
Post top
Colour housing
Grey
Protection class
II
Conductor cross section
2.5mm²
Surface protection
Powder coating
Lamp holder
None
Width
330mm
Type of control gear
LED operating device current-controlled
Material cover
Glass structured
Material housing
Aluminium
Impact strength
IK08
Suitable for number of lamps
1
Length
560mm
With connection cable
With light sensor
Colour rendering index CRI
70-79
Number of poles
2
Luminaire with limited surface temperature, sign "D“
Height/depth
215mm
With control gear
Nominal voltage
220 .. 240V
Rated luminous flux according to IEC 62722-2-1
5000lm
Colour temperature
4000 .. 4000K
Suitable for spigot size
42 .. 76mm
With light source
Degree of protection (IP)
IP66
Colour of light
White
Nominal current
1000 .. 1000mA
Lamp type
LED not exchangeable
Max. system power
37W
Adjustable optics
With radio control
Remote control
None
With light regulation program control
Dimming phase cut-on
Colour consistency (McAdam ellipse)
SDCM5
IFTTT support available
Dimming phase cut-off
Rated ambient temperature according to IEC62722-2-1
-25 .. 40°C
Dimming programmable
Dimming 1-10 V
Dimming potentiometer (integrated)
Dimming Sine Wave Reduction
Dimming mains voltage modulation
Dimming RF
Dimming DMX
Dimming DALI
Constant light output (CLO)
Dimming 0-10 V
Dimming Touch and Dim
Type of wiring
Ending
Dimming manufacturer's proprietary system
Dimming LineSwitch
No dim function
Dimming with push-button
Light distributor
Reflector
Dimming Zigbee
Luminaire efficacy
135lm/W
Operation by Bluetooth
Type of connection for sensor/communication module
Other
Compatible with Amazon Alexa
Compatible with Apple HomeKit
Compatible with Google Assistant
Dimming DSI
Exchangeable control gear
Power factor
0.9
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
