Details
- •Luminaires
- •Luminaire for streets and places
- •1 KOM
- •GEWISS
Technical specifications
Number of poles2
Protection classII
With light sensorNo
Mounting methodPost top
Height/depth215mm
Type of control gearLED operating device current-controlled
Conductor cross section2.5mm²
Voltage typeAC
Connection typeScrewed terminal
Length560mm
Colour rendering index CRI70-79
Colour housingGrey
Surface protectionPowder coating
Lamp holderNone
Material housingAluminium
Width330mm
Material coverGlass structured
Lamp typeLED not exchangeable
With connection cableNo
Impact strengthIK08
Colour temperature4000 - 4000K
Degree of protection (IP)IP66
Remote controlNone
Dimming 1-10 VYes
Luminaire with limited surface temperature, sign "D“No
Colour of lightWhite
With control gearYes
With light sourceYes
Dimming 0-10 VNo
Adjustable opticsNo
Suitable for spigot size42 - 76mm
Rated luminous flux according to IEC 62722-2-19900lm
Colour consistency (McAdam ellipse)SDCM5
Type of wiringEnding
Rated ambient temperature according to IEC62722-2-1-25 - 40°C
Max. system power74W
Nominal voltage220 - 240V
Nominal current1000 - 1000mA
With light regulation program controlNo
Suitable for number of lamps2
Constant light output (CLO)No
With radio controlNo
IFTTT support availableNo
Dimming with push-buttonNo
Dimming potentiometer (integrated)No
No dim functionNo
Compatible with Apple HomeKitNo
Dimming phase cut-onNo
Dimming programmableNo
Compatible with Google AssistantNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming DALINo
Compatible with Amazon AlexaNo
Light distributorReflector
Dimming DSINo
Dimming manufacturer's proprietary systemNo
Dimming DMXNo
Dimming LineSwitchNo
Luminaire efficacy134lm/W
Dimming mains voltage modulationNo
Operation by BluetoothNo
Dimming phase cut-offNo
Dimming RFNo
Exchangeable control gearYes
Power factor0.9
Type of connection for sensor/communication moduleOther
